All electrical, plumbing, waterproofing and construction completed by certified tradespeople.

9.6m L x 2.4m W x 4.3m H

Steel Frame

Black Aluminium Windows (detailed below)

Insulation Batts Earthwool R 2.5

Insulation Subfloor R 1.4

Waterproof Engineered Vinyl Floor Boards

VJ Panelling on all interior surfaces

Fully Painted - 1x colour option

Fully transportable and road registerable. Built on a 9.6m x 2.4m durable, heavy duty trailer chassis. All components are assembled and built in accordance to custom engineering specifications.

GVM: 4.5 tonne

Electric Brakes

Breakaway system

Hand brake system

4x stabilising legs

780mm Flat Deck with underfloor insulation cavity

Windows and Doors

Sliding Window 1200H x 1500W + Fly Screen

Fixed Window 1800H x 1800W

1 x 2100H x 1800W Sliding Door

Electrical

Double Power Point behind lounge

Double Power Point behind TV

2 x LED Downlight

Windows and Doors

2 x 600H x 2000W Sliding Window + Fly Screen

Cabinetry

Kitchen Cabinets + Overheads (as per design)

Laminate Benchtop

Soft touch close to doors and drawers where suitable

Electrical

4 x Double Power Points

Smoke alarm

2 x LED downlights

Fittings

Choice of Colour/Type Kitchen Tap

Choice of Colour/Type Cabinet Handles

Choice of Colour/Type Sink

Appliances

Stainless Steel Gas Cooktop 2 Burners

Stainless Steel Electric Built-in Oven

Slide-out Built-in Rangehood

Windows and Doors

1200H x 500W louvres with toughened glass

2 x Cavity sliding doors 2040H x 720W with privacy locks

Electrical

2 x Double Power Points

Extractor Fan

2 x LED downlight

Cabinetry

Bathroom Vanity + Mirror

Washing machine cavity (as per design)

Fittings

Choice of Colour/Type basin mixer

Choice of Colour/Type shower mixer

Choice of Colour/Type shower head

Choice of Colour/Type sink

Toilet/Shower

GreenLoo GL90 composting toilet

900 x 900mm shower with choice of framed shower screen

Windows and Doors

• 2100H x 1800W Sliding door + Fly Screen

• 1200H x 1500W sliding window + Fly Screen

Electrical

• 2 x Double Power Points with USB

• 2 x LED Downlights

Cabinetry

• Storage robes (as per design)

Features

• Suitable for Queen Bed

Safety Switchboard

Power Inlet 15 AMP

Colorbond steel roof and wall cladding

Water Inlet

2 x External Lights

Dual Gas Regulator

Gas Hot Water System
